Openstack(Juno) Neutron config params

Controller (with network node)

  • neutron.conf

egrep -v '^$|^#' neutron.conf

[DEFAULT]
verbose = False
debug = False
state_path = /var/lib/neutron
lock_path = $state_path/lock
api_paste_config = api-paste.ini
core_plugin = ml2
service_plugins = router
allow_overlapping_ips = True
auth_strategy = keystone
notify_nova_on_port_status_changes = True
notify_nova_on_port_data_changes = True
nova_url = http://controller:8774/v2
nova_admin_username = nova
nova_admin_tenant_id = service_tenant_id
nova_admin_password = nova_pass
nova_admin_auth_url = http://controller:35357/v2.0
nova_api_insecure = False
send_events_interval = 2
rabbit_hosts=controller1,controller2,controller3
rabbit_userid=openstack
rabbit_password=password
rabbit_virtual_host=/
rabbit_ha_queues=true
dhcp_agents_per_network = 3
agent_down_time=15
allow_automatic_l3agent_failover = True
[agent]
root_helper = sudo /usr/bin/neutron-rootwrap /etc/neutron/rootwrap.conf
report_interval = 5
[keystone_authtoken]
auth_uri = http://controller:5000
identity_uri = http://controller:35357
admin_tenant_name = service
admin_user = neutron
admin_password = neutron_pass
[database]
connection = mysql://neutron:pass@controller/neutron
idle_timeout=240
  • ml2_conf.ini

egrep -v '^$|^#' plugins/ml2/ml2_conf.ini

[ml2]
type_drivers = flat,vlan
tenant_network_types = vlan
mechanism_drivers = openvswitch
[ml2_type_flat]
flat_networks = physnet1
[ml2_type_vlan]
network_vlan_ranges = physnet1:1000:2999
[securitygroup]
enable_security_group = True
enable_ipset = True
firewall_driver = neutron.agent.linux.iptables_firewall.OVSHybridIptablesFirewallDriver
[ovs]
tenant_network_type = vlan
bridge_mappings = physnet1:br0
  • dhcp_agent.ini

egrep -v '^$|^#' dhcp_agent.ini

[DEFAULT]
debug = False
interface_driver = neutron.agent.linux.interface.OVSInterfaceDriver
ovs_integration_bridge = br-int
dhcp_driver = neutron.agent.linux.dhcp.Dnsmasq
use_namespaces = True
enable_isolated_metadata = False
enable_metadata_network = False
dnsmasq_dns_servers = 114.114.114.114
  • metadata_agent.ini

egrep -v '^$|^#' metadata_agent.ini

[DEFAULT]
debug = False
auth_url = http://controller:5000/v2.0
auth_region = RegionOne
admin_tenant_name = service
admin_user = neutron
admin_password = neutron_pass
nova_metadata_ip = controller
nova_metadata_port = 8775
nova_metadata_protocol = http
metadata_proxy_shared_secret = shared_secret
  • l3_agent.ini

egrep -v '^$|^#' l3_agent.ini

[DEFAULT]
debug = False
interface_driver = neutron.agent.linux.interface.OVSInterfaceDriver
use_namespaces = True
external_network_bridge =

Compute

  • neutron.conf

egrep -v '^#|^$' neutron.conf

[DEFAULT]
verbose = False
debug = False
state_path = /var/lib/neutron
lock_path = $state_path/lock
api_paste_config = api-paste.ini
core_plugin = ml2
service_plugins = router
allow_overlapping_ips = True
auth_strategy = keystone
notify_nova_on_port_status_changes = True
notify_nova_on_port_data_changes = True
nova_url = http://controller:8774/v2
nova_admin_username = nova
nova_admin_tenant_id = service_tenant_id
nova_admin_password = nova_pass
nova_admin_auth_url = http://controller:35357/v2.0
nova_api_insecure = False
send_events_interval = 2
rabbit_hosts=controller1,controller2,controller3
rabbit_userid=openstack
rabbit_password=password
rabbit_virtual_host=/
rabbit_ha_queues=true
dhcp_agents_per_network = 3
agent_down_time=15
allow_automatic_l3agent_failover = True
[agent]
root_helper = sudo /usr/bin/neutron-rootwrap /etc/neutron/rootwrap.conf
report_interval = 5
[keystone_authtoken]
auth_uri = http://controller:5000
identity_uri = http://controller:35357
admin_tenant_name = service
admin_user = neutron
admin_password = neutron_pass
[database]
connection = mysql://neutron:pass@controller/neutron
idle_timeout=240
  • ml2_conf.ini

egrep -v '^#|^$' plugins/ml2/ml2_conf.ini

[ml2]
type_drivers = flat,vlan
tenant_network_types = vlan
mechanism_drivers = openvswitch
[ml2_type_flat]
flat_networks = physnet1
[ml2_type_vlan]
network_vlan_ranges = physnet1:1000:2999
[securitygroup]
enable_security_group = True
enable_ipset = True
firewall_driver = neutron.agent.linux.iptables_firewall.OVSHybridIptablesFirewallDriver
[ovs]
tenant_network_type = vlan
bridge_mappings = physnet1:br0

Create public network

neutron net-create external-net --provider:network_type vlan --provider:physical_network physnet1 --provider:segmentation_id 60 --router:external

Architecture

server with switches

controller/network node virtual devices inside

compute virtual devices insed

reference

  1. Openstack Networking (Type driver vlan and Openvswitch)

  2. Openstack neutron network setup

Written on January 26, 2016
